- Powered by the AIoT-specific ARM architecture octa-core processor and the latest Android 14 OS
- With 8GB of RAM and 128GB of ROM, multitasking is a breeze
- Built in 7200mAh battery, provides up to 11 hours of use on a single charge
- Dual-Band Wi-Fi 5 for higher speed transmissions
- BT 5.1 with greater range and higher speed
- 4G mobile network with high quality communication level
- Barcode Scanning (Optional) + NFC for diverse data collection needs
- 5MP + 13MP Dual Cameras for clear and detailed work documentation
- GPS/GLONASS/BEIDOU/Galileo/QZSS/SBAS multi-mode satellite positioning
- All-in-one design with IML technology for scratch resistance and durability
- IP65 waterproof and dustproof, MIL-STD-810H certified
- Stable operation in extreme temperatures of -10°C to 50°C
Other Pictures
· Specifications
| Basic Parameters |
| Dimension | 219 x 139 x 12.5mm |
| Device Color | Black |
| Weight | 524g |
| LCD | 8 inch FHD 16:10, 1200×1920, 550nits |
| Touch Panel | 10 point G+G capacitive touch screen |
| Camera | Front 5.0MP, with Light sensor Rear 13.0MP, Autofocus, Single flash |
| I/O | Type-C x 1(USB 2.0/OTG/Fast charge PE+2.0 18W), SIM Card x 2, TF Card x 1,Max:512G, (Two out of three Cato) 12PIN Pogo Pin x 1 |
| Power | USB Type-C interface, support fast charging PE + 2.0, Maximum Power 18W, Maximum 9V/2A. |
| Battery |
| Capacity | 3.8V/7200mAh |
| Type | Built-in Li-polymer battery |
| Endurance | 11hrs ( 50% volume sounds, 50% screen brightness, 1080P HD video display by default ) |
| Performance Parameter |
| CPU | ARM (Octa-Core) |
| OS | Android 14/GMS |
| RAM | 8GB |
| ROM | 128GB |
| Communication |
| WIFI | WIFI 802.11 a/b/g/n/ac 2.4G+5.0G(5.1G+5.8G) Dual-band WIFI |
| Bluetooth | BT5.1(BLE) class 1 Transmission distance: 10m |
| 2G/3G/4G | GSM: B2/3/5/8 WCDMA:B1/2/5/8 FDD:B1/2/3/4/5/7/8/17/20/28A/28B TDD:B38/39/40/41 |
| GNSS | Support GPS/GLONASS/BEIDOU/Galileo/QZSS/SBAS |
| Reliability |
| Operate Temperature | -10 °C ~ 50 °C |
| Store Temperature | -20 °C ~60 °C |
| Humidity | 95% Non-Condensing |
| Rugged Feature | IP65 certified, MIL-STD-810H certified |
| Drop Height | 1.22m |
| Data Collection |
| NFC | Built-in, 13.56MHz, Support ISO/IEC 14443A/B/15693/18092 mifare protocols Card reading distance: 2.5-4cm |
| 2D | Optional Optical resolution: ≥3mil Code system: 1D：Code128、EAN-13、EAN-8、UPC-E、UPC-A、 ISBN、ISSN、Code11、Interleaved 2 of 5、 Code39、Code93、Code32、Codabar、Matrix 2 of 5、 Industrial 25、IATA25、MSI Plessey、GS1 DataBar、Plessey、Febraban、Composite 2D：QR Code、Micro QR、Data Matrix、PDF417、 Micro PDF417、Aztec、Maxicode、Han Xin code、Dotcode |
